Principle:

The variable speed fluid couplings is a power-delivering equipment with liquid, the drive machine revolve the pump, under the action of the centrifugal force, the liquid driving by the pump blade move to top of the blade from root and form high-pressure and super-speed liquid and rush at the turbine blade and make the turbine follow the pump to round as the same direction, the liquid move to root of the turbine blade from top and get deceleration and decompression then go into the pump, the liquid continue to circle as the mode, the pump transform machine energy of the drive machine into kinetic energy and potential energy of the liquid, then the turbine transform kinetic energy and potential energy of the liquid into machine energy of the export shaft, energy-delivering has been gotten. Regulating the speed of working-machine steplessly and keeping the speed of the drive machine constant can be realized just change the amount of the liquid in the working-chamber.

Function:
Regulating speed steplessly;
No-load or light-load to start the heavy carry;
Insulating twist vibration;
Over-load protection;
The high-efficiency delivering power ;
Apt to get automatic control.

Use:
All kinds of water pump and fan, which need change load to run, can choose the variable speed fluid couplings to get regulating speed steplessly and energy-saving. Our product have extensive been used in the metallurgy, the mine, the chemical engineering, the petroleum, the power plant, the cement, the municipal feed-water and feed-vapor, the light-industry, the spin and weave and so on. It is an energy- saving product recommended stress by government.

Constant Filling Fluid Coupling

I Characteristic
1. Increasing the starting performance of motor, reducing the starting current, and shortening the starting time.
2. Overload protection. Able to prevent the motor from being burnt out in case of overload.
3. Able to fully use the maximum torque of motor to start the great inertia working machine, reducing the installed capacity.
4. Able to isolate torsional oscillation, decrease shock and vibration and prolong the service life of equipment.
5. Able to automatically adjust the load of motor in a multi driving motor.
6. Simple in construction, reliable operation and free of mechanical wear, easy maintenance.

II Application
1. Hoisting and transport machinery: belt , drag-flight , chain-linked conveyer, various types of hoister , portal or bridge crane, etc.
2. Mining machinery: ball mill, crusher, coal planer, mine hoister, bucket wheel excavator, etc.
3. Building machinery: mixer, road roller, tower crane, stone cut-off machine, brick machine, grinder, etc.
4. Metallurgical equipment: straightening machine, cold-draw machine, extruder, rolling mill, coke pusher, fan, pump, etc.
5. Chemical machinery: centrifuge, rubber processing machine, mixer, kneader, mixing agitator, dryer, etc.
6. Other machinery: ceramic equipment, papermaking equipment, glass-making equipment, plastic machinery, textile machinery, foundry machinery, etc.

Ⅲ Type
Symbol “ Y O X□ □” ：Y O means fluid coupling, X means constant moment, suffix □ is characteristic symbol, p means belt wheel, nz means brake wheel, no sign means basic type. The last □ means specs, wheel criterion size.

Ⅴ Capability
1. The rated slip is ≤4%
2. The ratio of over-load is 2~2.5

Ⅵ Size and power
1. Size: 250~1150 (wheel criterion size, mm)
2. Power transfer: 0.7~1300 kW

Ⅶ Species
1. Basic type YOX Ⅰ: Connected using elastic pins at the export end; adjusting, assembling and disassembling are easy.
2. Basic type YOX Ⅱ: Connected to the diaphragm coupling at the export end; assembling and disassembling is easy
3. Basic type YOX Ⅲ: Connected to the diaphragm coupling at the both end; assembling and disassembling is easy, but the axial is longer
4. Basic type YOX Ⅳ: Connected using pins; with shorter axial length.
5. YOX p: Belt wheel connecting at the export end;
6. YOXnz: With brake wheel.
